Common questions
Do mango pulp and mango puree require separate production lines?
The names overlap in commercial use. The important selection is the finished texture, fibre profile, composition and intended use. The same whole-fruit route can be configured with appropriate extraction and finishing equipment; a second line is not required simply because the product name changes.
Does the line need a separate mango peeling machine?
The mango extraction equipment shown combines peel and stone separation with pulp extraction. The line is configured around that actual machine. A standalone peeling stage is not assumed in this arrangement.
Why is a finisher shown after the combined destoner?
The destoner handles primary separation from whole fruit. The finisher works on extracted pulp, screening it to separate coarser material from the accepted product. Its screen arrangement is selected for the required fibre and texture.
Does a fruit-processing rate describe the final pulp output?
No. Whole-fruit input includes material later removed during sorting, destoning and refining. Finished-pulp output needs a defined collection boundary and corresponding measurements. Pulp volume flow also requires density before it can be compared with mass flow.
Can concentration be added to an existing pulp line?
Yes. The concentration scope can begin at prepared pulp, with buffering, evaporation and concentrate transfer connected to the existing process. Selection needs the actual feed, target concentrate, utility supply and onward product route.
Must pulp be concentrated before aseptic filling?
No. Concentration and packaging are separate decisions. Single-strength pulp and concentrate can each be considered for aseptic bags when the thermal and filling systems are configured for the product.
Can an existing pulp front end be retained when adding aseptic bags?
A downstream project can start at the existing pulp handover. Its feed conditions, sustained supply, cleaning connections and product specification need to match the new buffer, thermal unit and filler.
Can every bag size be used on the twin-head filler shown?
Bag and fitment compatibility is specific to the selected filling configuration. The family offers different bulk-pack formats, but bag size, supporting container, fill quantity and handling arrangement must fit the installed heads and product duty.
What sterilization temperature and holding time should mango pulp use?
There is no universal setting for every mango product. The equipment has a configured operating range, while the process must be established for the actual composition, flow behaviour, microbiological targets and package system. An adjustable machine range is not a validated product recipe.
Does the CIP system clean the entire fruit front end automatically?
No. Conveyors, brushes and other open surfaces need their own accessible cleaning procedures. Destoner and finisher parts may require opening or removal according to their design. CIP serves the suitable closed circuits identified in the cleaning arrangement.
Can individual machines be purchased for an existing mango line?
The equipment scope can cover an individual machine or a connected group. Match its feed condition, discharge arrangement, controls and cleaning connections to the machines already in the plant.
Do I need a complete technical specification before making an enquiry?
No. Start with the line or machine you need and a short description of the material and intended product. Approximate capacity, existing equipment and packaging details are useful optional additions.
